Welded Wire Mesh Panel

Welded Wire Mesh Panel is made of superior quality welded mesh, with flat even surface, firm structure, be used extensively in building, food, agriculture and so on.

1. Material of Welded Wire Mesh Panel
Low carbon steel wire,galvanized iron wire,stainless steel wire and PVC coated wire.

2. Assortments available of Welded Wire Mesh Panel

  • Galvanized Welded Mesh Panels
  • Stainless Steel Wire Mesh Panels
  • Hot-dip Zinc Plating Welded Mesh Panels
  • PVC coated Welded Mesh Panels

3. Application of Welded Wire Mesh Panel
Widely used in construction reinforcement, the ground for the tunnels, bridges, highway, airport and wharf, construction of wall body, also in decorative architecture.

4. Advantages of Welded Wire Mesh Panel
Welding firm, mesh hole even, the mesh surface smooth, corrosion resistance, strength, protective capability is strong.

5. Processing of Welded Wire Mesh Panel

  • Hot dipped galvanizing before welding
  • Hot dipped galvanizing after welding
  • Welding with iron wire
  • Electric galvanizing after welding
  • PVC coated welded wire mesh panel

6. Packing of Welded Wire Mesh Panel
In wooden or steel pallet, 50 to 500 piece per pallet. (Customer’s packing is available on request.)

Products Information

Material Low carbon steel wire, galvanized wire, stainless steel wire, aluminum-magnesium alloy wire
Process Welded after galvanized and galvanized after welding
Mesh 75mm x 150mm
Size 1800mm x 3000mm(or more)
PVC Coating Thickness 0.5mm ~ 1.0mm
Packing Bare or pallet

Common Specification

Wire Diameter Mesh Width
inch mm
2.0mm ~ 3.2mm 1" 25.40 0.914m ~ 1.83m
2.0mm ~ 4.5mm 2" 50.80 0.914m ~ 2.75m
2.0mm ~ 6.0mm 3" 70.20 0.914m ~ 2.75m
2.0mm ~ 6.0mm 4" 101.6 0.914m ~ 2.75m
2.0mm ~ 6.0mm 5" 127.0 0.914m ~ 2.75m
2.0mm ~ 6.0mm 6" 152.4 0.914m ~ 2.75m
2.0mm ~ 6.0mm 7" 177.8 0.914m ~ 2.75m
2.0mm ~ 6.0mm 8" 203.2 0.914m ~ 2.75m
